MOTOROLA SOLUTIONS MOTOTRBO CATALOG MOTOTRBO™ R7 SERIES MOTOTRBO™ R7 offers game-changing audio capabilities in a rugged, future-ready device. Its advanced audio processing ensures that your communications are loud and clear, and advanced connectivity options get your workforce ready for tomorrow. EVOLVE LTE HANDHELD Evolve combines the data capabilities of an Android device with the ruggedness and reliability of a business-critical push-to-talk device. A CBRSready LTE handheld built for business, it is ready to evolve with your changing network needs. SM SM
2 | 800-503-3433 • WWW.DAYWIRELESS.COM CONTENTS 03 MOTOTRBO RADIO SOLUTIONS 23 WAVE PTX (PUSH-TO-TALK SERVICE) 32 SAFETY REIMAGINED 44 AVTEC 54 NITRO
3 | 800-503-3433 • WWW.DAYWIRELESS.COM MOTOTRBO RADIO SOLUTIONS
4 | 800-503-3433 • WWW.DAYWIRELESS.COM MOTOTRBO RADIO SOLUTIONS MOTOTRBO® A COMPLETE END-TO-END SOLUTION Having MOTOTRBO at the heart of your organization will help you achieve new levels of productivity, safety and efficiency. The extensive portfolio means you can custom-build your complete solution, including radios, infrastructure, systems, accessories, applications and services designed around what you need today and in the future. INSTANTANEOUS PTT COMMUNICATION Nothing is faster than push-to-talk (PTT) when you need a quick answer or immediate emergency response. It provides real-time communication for individuals or groups across your entire team from the control room to the front line, resulting in loyal customers, satisfied employees and increased business. HEAR AND BE HEARD CLEARLY IN NOISY ENVIRONMENTS Superb audio quality means MOTOTRBO delivers crystalclear communications. The Intelligent Audio feature automatically adjusts radio volume up and down in response to the level of noise in the workplace. And with MOTOTRBO’s background noise suppression, you can be confident communication is loud and clear. REACH YOUR WORKFORCE WHEREVER THEY GO Hear calls clearly over a greater range. MOTOTRBO features advanced digital signal processing to deliver voice integrity and clarity to the limits of coverage. And thanks to DMR TDMA technology, MOTOTRBO delivers twice the call capacity of analog radios so more workers can use voice and data, without worrying about privacy or interference. CHOOSE THE RIGHT SOLUTIONS FOR THE RIGHT USERS Whether you want ultra-light portables or extra tough mobiles, integrated Bluetooth® and Wi-Fi® or industry-leading data applications, MOTOTRBO has the right devices and systems to fit your workforce now and allows you to evolve as your enterprise grows. LEVERAGE EXPERT APPLICATIONS THAT GET THE JOB DONE EFFICIENTLY MOTOTRBO fits the way businesses run today, with an expert Application Developer Program that helps you customize your communication solution to your environment and workforce. Solutions range from text messaging, centralized dispatch and GPS tracking to personnel monitoring and work order ticket management. Applications like these make it easier to accomplish multiple tasks on a single purpose-built device.
5 | 800-503-3433 • WWW.DAYWIRELESS.COM GET ADVANCED CAPABILITIES AND BUSINESS-CRITICAL FEATURES MOTOTRBO has innovative features such as Transmit Interrupt, which lets you prioritize communication the moment it’s needed. ManDown and Lone Worker applications call for help when personnel can’t. GPS location tracking monitors vehicles, assets and the user in real time. KEEP CONNECTED WHEN CONDITIONS ARE TOUGHEST MOTOTRBO is made to last. Our rugged, waterproof and intrinsically safe radios endure a rigorous Accelerated Life Testing (ALT) purpose-built device that simulates up to 5 years of field use. We design and engineer MOTOTRBO products to survive the harsh conditions of everyday business. REACH EVERYONE, ANYWHERE When you’re running a professional operation, you need more than just radio-to-radio communications. MOTOTRBO has coverage options to suit your needs – whether you’re operating in a single building, a large campus or even multiple locations around the world. Connecting thousands of radio and smartphone users in a single location, your capacity options are virtually unlimited. KEEP COMMUNICATING FOR LONGER Because MOTOTRBO radios use much less power in digital mode than analog, batteries last significantly longer on a single charge. VIDEO MOTOTRBO RADIO SOLUTIONS
6 | 800-503-3433 • WWW.DAYWIRELESS.COM MOTOTRBO RADIO SOLUTIONS The demands of today’s workforce and the nature of business communications have made it increasingly complicated to equip your teams with devices adequate for the challenges of their environment, while delivering long-term value. Communications now span across several types of networks and devices for voice and data, but the main focus is still keeping your teams and customers safe, while making your operations more efficient and connected. In order to achieve these goals, your teams are monitoring video, access control, and more. Those technologies should not be siloed — you are stronger, more, proactive and responsive when everything under your technology stack is connected and works together. So where do you start when evaluating different commutation options? It’s a lot to consider, but it starts with the devices that your teams use daily, and rely on as their lifeline. PURCHASING FOR PROFESSIONAL COMMUNICATIONS MOTOTRBO RADIOS CP 100d CP 100d CP 100d CP 200d SL 300 CM300d CM200d COMMERCIAL VOICE ION PREMIUM VOICE, BROADBAND DATA, ANDROIS OS ENTRY PROFESSIONAL XPR 2500 VOICE, BASIC SYSTEMS PROFESSIONAL ENHANCED XPR 5000E HCH XPR 5550e XPR 5580e SUPERB VOICE, ENHANCED DATA, SYSTEMS, FEATURES XPR 5550e XPR 5580e XPR 7550 I.S. XPR 7580e I.S. SPECIALIZED (CANADA) HAZERDOUS LOCATION XPR 3300e SL3500e XPR 3500e R7 SL 7550e SL 7580e SL 7590e R7
7 | 800-503-3433 • WWW.DAYWIRELESS.COM MOTOTRBO RADIO SOLUTIONS 4 CAPABILITIES Data communications are now at the forefront of day-to-day business operations. Much of what was previously be radio traffic is now consumed as data, on a number of different applications, programs and devices. As a result, many teams are carrying multiple devices. The challenge is that many of the data devices available — and the networks they operate on — are not built for business and may compromise on durability, security and control. Voice remains a critical communication need for businesses. There is no true substitute for one-to-many voice communication on rugged, purpose-built devices that operate on private custom-built networks — when it matters most. That’s why Motorola Solutions now offers converged and collaborative communication devices. Converged devices, like MOTOTRBO Ion, can offer the best of both worlds in data and voice. The Ion smart radio brings together renowned Push-to-Talk (PTT) performance, an open app ecosystem on the Android platform, and access to Motorola Solutions’ unified technology ecosystem — from video security and analytics solutions, to best-in-class network security, to powerful new software and technology services. Collaborative devices, like R7, are designed to complement more data-intensive devices in your fleet, and also collaborate with other tools like video, sensors, etc. More on that in the next section. Clear audio is among the most prominent radio features for both the end-user and the buyer. The ability to hear and be heard the first time is crucial for staff productivity and the safety of your team and your customers. All MOTOTRBO radios have basic noise-canceling features, but more advanced features are available with higher-tier radios, with the newest Dual Microphone Noise Suppression available only on MOTOTRBO Ion and R7. DATA CONVERGED VS COLLABORATIVE AUDIO BUYING GUIDE | MOTOTRBO TWO-WAY RADIOS
8 | 800-503-3433 • WWW.DAYWIRELESS.COM MOTOTRBO RADIO SOLUTIONS 5 BUYING GUIDE | MOTOTRBO TWO-WAY RADIOS CAPABILITIES Motorola Solutions has developed the first and only technology ecosystem that unifies voice, video, data, and analytics in a single platform, enabling individuals, businesses and communities to work together in more powerful ways. We call it Safety Reimagined. Our MOTOTRBO portfolio is built within this ecosystem so you can get more out of your communications investment. Keep your teams aware and streamline critical communications by receiving automatic notifications from your video security and access control systems, sensors and more — directly on your device, using Orchestrate. Control and consolidate instant voice communications from your desktop using innovative computer-aided dispatch solutions. And extend communications beyond your radio network with interoperability with flexible broadband push-to-talk solutions INTEGRATION ORCHESTRATE Orchestrate is a simple-to-configure, cloud-based interface tool that gives administrators the ability to configure and automate security workflows that control their integrated technology ecosystem.
9 | 800-503-3433 • WWW.DAYWIRELESS.COM MOTOTRBO RADIO SOLUTIONS 6 BUYING GUIDE | MOTOTRBO TWO-WAY RADIOS CAPABILITIES Business communications devices must be built ready to withstand harsh and unpredictable environments. Ingress/International Protection (IP ratings) are industry-standard durability ratings. The first number in the rating refers to protection against solid objects, and the second refers to protection against liquids. MOTOTRBO radios start at IP54 and top out at IP68. Hazardous location certifications are sought after for environments where flammable or explosive gases, liquids, dust, or “flyings” may be encountered. Health and safety regulations often mandate that products used in these areas must be HazLoc-certified. # OBJECT SIZE EXAMPLE 0 – No protection against contact and ingress of objects 1 >50 mm Protected against large objects 2 >12.5 mm Protected against fingers 3 >2.5 mm Protected against tools 4 >1 mm Protected against wires 5 Dust Dustproof: Dust may enter, but not enough to interfere with product operation 6 Dust Dust-tight. No dust may enter # PROTECTION 0 Not protected against liquid intrusion 1 Protected against vertical dripping water 2 Protected against water dripping at an angle 3 Protected against spraying water 4 Protected against splashing water 5 Protected against water jets 6 Protected against powerful water jets 7 Protected against immersion (up to 1m / 3f t for 30 mins) 8 Protected against immersion (beyond 1m / 3f t - Motorola tests to 2m / 6.6 f t for 2 hrs) HAZLOC CERTIFIED MODELS ARE AVAILABLE STARTING AT THE ENTRY PROFESSIONAL TIER AND UP. INTRINSICALLY SAFE* MODELS ARE PROFESSIONAL ENHANCED TIER AND UP. DURABILITY *Intrinsically Safe is an equipment design protection method for Division 1 which encompasses hazards that may be present under normal operating conditions or frequently present during maintenance and repair work.
10 | 800-503-3433 • WWW.DAYWIRELESS.COM MOTOTRBO RADIO SOLUTIONS 7 BUYING GUIDE | MOTOTRBO TWO-WAY RADIOS CONNECTIVITY Every MOTOTRBO radio is capable of direct radio-to-radio communication without repeaters or radio systems, and used with Single Site Conventional systems. A conventional system is a step up from basic radio-to-radio communications, where radios communicate via a high-power repeater, giving better coverage and more centralized control. Our Commercial radios are designed for direct mode or single-site conventional systems. PTT over LTE is available exclusively for MOTOTRBO radios in the Professional Enhanced tier and up, enabling nationwide PTT, a unique value-add thanks to our WAVE PTX service. Full Wi-Fi broadband data is available on the Premium tier, MOTOTRBO Ion, allowing for carrier-network LTE and private LTE with our Nitro network and also quicker updating, programming and provisioning over LTE. Bluetooth connectivity allows for MOTOTRBO devices to connect to audio and data applications. Bluetooth accessories are an attractive option to enhance the audio experience, such as remote speaker microphones and headsets. Bluetooth also provides a way for MOTOTRBO radios to connect to devices such as Honeywell Gas Sensors. MOTOTRBO systems offer several advantages over conventional systems and direct mode, such as more user capacity, customized coverage and increased control. Systems can be deployed for single- or multi-site, employing dynamic trunking to increase capacity, for up to 3000 users per site, and up to 250 configurations. MOTOTRBO systems are the backhaul for not only voice but also data for a network of applications developed specifically by and for users. Our Entry-Level Professional radios are designed for use on our Capacity Plus Systems, and Professional Enhanced for Capacity Max systems. Wi-Fi connectivity can provide radio managers with the opportunity to remotely program radios faster than over DMR, without taking them out of the field. Wi-Fi connectivity is available for programming and for PTT over Wi-Fi via WAVE PTX, for the Professional Enhanced tier radios. PTT through WAVE PTX allows for dead spot mitigation for places where MOTOTRBO systems were not designed to reach. Full Wi-Fi data is available on the Premium tier with MOTOTRBO Ion. DIRECT MODE/SINGLE SITE CONVENTIONAL LTE BLUETOOTH MOTOTRBO DMR SYSTEMS WI-FI SYSTEMS
11 | 800-503-3433 • WWW.DAYWIRELESS.COM MOTOTRBO RADIO SOLUTIONS 8 BUYING GUIDE | MOTOTRBO TWO-WAY RADIOS COVERAGE MOTOTRBO systems empower teams with custom voice coverage to keep you connected when it counts, anywhere you do business. MOTOTRBO systems combine superior signal strength with the flexibility to customize site coverage, a predictable cost structure built around your needs, the control to decide which features and which devices go on your network, capacity for as many devices as your team needs, and the capabilities to ensure that your team is only a button’s push away. While all DMR radios are designed to a standard that enables interoperability between different brands — both systems and devices — MOTOTRBO radios have the ability to work in conjunction with a number of different devices over broadband data networks thanks to WAVE PTX. Our WAVE PTX application gives the ability for smartphones, tablets, and other devices to connect with MOTOTRBO over LTE and Wi-Fi. DMR, Wi-Fi, and LTE all provide the option for voice interoperability through MOTOTRBO, but handover between these devices requires manual intervention from the end-user. MOTOTRBO’s Seamless Voice Handover maintains your voice communications by automatically switching to broadband when your radio signal fades. Authentication, status, talkgroups, and encryption are all preserved, without interruptions or resets. CUSTOMIZED COVERAGE WITH MOTOTRBO INTEROPERABILITY DEVICE HANDOVER
12 | 800-503-3433 • WWW.DAYWIRELESS.COM PORTABLE AND MOBILE RADIOS The MOTOTRBO two-way radio portfolio offers you a wide choice of devices, from simple voice-only models to feature-rich voice and data radios. All devices work together seamlessly to deliver advanced features to enhance your safety, productivity and efficiency. With exceptional voice quality and outstanding usability, MOTOTRBO keeps your workforce connected. MOTOTRBO RADIO SOLUTIONS
13 | 800-503-3433 • WWW.DAYWIRELESS.COM MOTOTRBO RADIO SOLUTIONS CP100d SIMPLE AND EFFECTIVE FOR THE LIGHT USER WHO VALUES EASE AND EFFICIENCY Communicate simply and efficiently. The CP100d Series gives you streamlined analog voice communications, and MOTOTRBO digital when you’re ready. Easy to use and practical, the CP100d Series provides a straightforward path to digital migration. COMPATIBLE WITH: CP200d SIMPLE VOICE COMMUNICATIONS FOR THE EVERYDAY USER WHO WANTS TO STAY CONNECTED Communicate simply and clearly. The CP200d gives you affordable analog voice communications, with the option to upgrade to MOTOTRBO digital when you’re ready. With great performance and rugged durability, the CP200d simply keeps your workforce connected. COMPATIBLE WITH: SL300 SLIM AND STYLISH, FOR THE CUSTOMER SERVICE USER WHO NEEDS INTUITIVE TECHNOLOGY Connect to intuitive technology with this slim, lightweight radio. An eye-catching Active View display combines ruggedness with simplicity, and patented Range Max technology delivers great coverage with long battery life in a small, convenient outline. The radio supports analog and digital modes, and is complemented by a range of innovative accessories. COMPATIBLE WITH: CM SERIES SIMPLE VOICE COMMUNICATIONS FOR THE EVERYDAY USER WHO WANTS TO STAY CONNECTED Communicate simply and safely. CM200d and CM300d radios give you affordable analog voice communications, with the option to upgrade to MOTOTRBO digital when you’re ready. With great performance and a straightforward user interface, the CM200d and CM300d simply keep your workforce connected. COMPATIBLE WITH: COMMERCIAL TIER IP SITE CONNECT CAPACITY PLUS CAPACITY MAX CONNECT PLUS IP SITE CONNECT CAPACITY PLUS CAPACITY MAX CONNECT PLUS IP SITE CONNECT CAPACITY PLUS CAPACITY MAX CONNECT PLUS IP SITE CONNECT CAPACITY PLUS CAPACITY MAX CONNECT PLUS
14 | 800-503-3433 • WWW.DAYWIRELESS.COM ENTRY PROFESSIONAL TIER = Optional SL 3500e INSTANT COMMUNICATION, PROFESSIONAL STYLE Slim, lightweight, and discreet, the MOTOTRBO SL3500e portable two-way radio gives you the power of instant two-way communication without compromising your style. Get quick access to key radio functions along with information at a glance. Connect discreetly to Bluetooth® earpieces and sensors. And access Wi-Fi networks for over-the-air software updates. COMPATIBLE WITH: XPR 3000e COMPACT AND CAPABLE, FOR THE BUSY WORKER WHO NEEDS TO COMMUNICATE EFFICIENTLY Connect with efficiency. The XPR 3000e Series delivers analog and digital voice capabilities, with support for basic systems and a feature-set geared to maximum workplace efficiency – including Wi-Fi for remote radio management and Bluetooth 4.0 (please check for availability). With excellent range and impressive battery life, these radios deliver cost-effective connectivity. COMPATIBLE WITH: XPR 2500 AFFORDABLE VOICE COMMUNICATIONS FOR THE BUSY PROFESSIONAL The power of digital is within reach. The XPR 2500 features voice systems capability, twice the calling capacity and clearer voice communications. With Intelligent Audio, drivers don’t need to adjust radio volume to avoid missing a call: the XPR 2500 monitors background noise and automatically adjusts itself. COMPATIBLE WITH: IP SITE CONNECT CAPACITY PLUS CAPACITY MAX CONNECT PLUS IP SITE CONNECT CAPACITY PLUS CAPACITY MAX CONNECT PLUS IP SITE CONNECT CAPACITY PLUS CAPACITY MAX CONNECT PLUS MOTOTRBO RADIO SOLUTIONS ENTRY PROFESSIONAL TIER = Optional SL 3500e INSTANT COMMUNICATION, PROFESSIONAL STYLE Slim, lightweight, and discreet, the MOTOTRBO SL3500e portable two-way radio gives you the power of instant two-way communication without compromising your style. Get quick access to key radio functions along with information at a glance. Connect discreetly to Bluetooth® earpieces and sensors. And access Wi-Fi networks for over-the-air software updates. COMPATIBLE WITH: XPR 3000e COMPACT AND CAPABLE, FOR THE BUSY WORKER WHO NEEDS TO COMMUNICATE EFFICIENTLY Connect with efficiency. The XPR 3000e Series delivers analog and digital voice capabilities, with support for basic systems and a feature-set geared to maximum workplace efficiency – including Wi-Fi for remote radio management and Bluetooth 4.0 (please check for availability). With excellent range and impressive battery life, these radios deliver cost-effective connectivity. COMPATIBLE WITH: XPR 2500 AFFORDABLE VOICE COMMUNICATIONS FOR THE BUSY PROFESSIONAL The power of digital is within reach. The XPR 2500 features voice systems capability, twice the calling capacity and clearer voice communications. With Intelligent Audio, drivers don’t need to adjust radio volume to avoid missing a call: the XPR 2500 monitors background noise and automatically adjusts itself. COMPATIBLE WITH: IP SITE CONNECT CAPACITY PLUS CAPACITY MAX CONNECT PLUS IP SITE CONNECT CAPACITY PLUS CAPACITY MAX CONNECT PLUS IP SITE CONNECT CAPACITY PLUS CAPACITY MAX CONNECT PLUS
15 | 800-503-3433 • WWW.DAYWIRELESS.COM R7 BREAK THROUGH THE NOISE. BE HEARD MOTOTRBO™ R7 is a digital portable two-way radio that offers game-changing audio capabilities in a rugged, future-ready device. Its advanced audio processing ensures that your communications are loud and clear, while its rugged construction is ready for harsh environments, and advanced connectivity options get your workforce ready for tomorrow. COMPATIBLE WITH: XPR 7000e POWERFUL AND SOPHISTICATED, FOR THE PROFESSIONAL WHO REFUSES TO COMPROMISE When you need complete connectivity, the XPR 7000e Series delivers. These portable radios have excellent range, battery life and audio quality in all digital and analog systems, and a full suite of features to enhance safety and productivity. And with integrated Wi-Fi, GPS and Bluetooth 4.0, you can be confident that your radio integrates the latest technology. COMPATIBLE WITH: XPR 5000e POWERFUL AND SOPHISTICATED, FOR THE PROFESSIONAL WHO REFUSES TO COMPROMISE When you need complete connectivity, the XPR 5000e Series delivers. These mobile radios have excellent range and audio quality in all digital and analog systems, and a full suite of features to enhance safety and productivity. And with integrated Wi-Fi, GPS and Bluetooth 4.0, you can be confident that your radio integrates the latest technology. COMPATIBLE WITH: IP SITE CONNECT CAPACITY PLUS CAPACITY MAX CONNECT PLUS IP SITE CONNECT CAPACITY PLUS CAPACITY MAX CONNECT PLUS IP SITE CONNECT CAPACITY PLUS CAPACITY MAX CONNECT PLUS PROFESSIONAL ENHANCED TIER ION CRITICAL VOICE. INSTANT DATA. ONE DEVICE. The MOTOTRBO™ Ion smart radio is the first business-ready communication device with all-on voice and broadband data capabilities. It combines the dependability and ruggedness of a MOTOTRBO two-way radio with the open app ecosystem of an Android device. COMPATIBLE WITH: IP SITE CONNECT CAPACITY PLUS CAPACITY MAX CONNECT PLUS R7 BREAK THROUGH THE NOISE. BE HEARD MOTOTRBO™ R7 is a digital portable two-way radio that off rs game-changing audio capabilities in a rugged, future-ready device. Its advanced audio processing ensures that your communications are loud and clear, while its rugged construction is ready for harsh environments, and advanced connectivity options get your workforce ready for tomorrow. C P TI LE IT : 7000e P ERF L S P ISTIC TE , F R T E PR FESSI L REF SES T C PR ISE hen you need co plete connectivity, the XPR 7000e Series delivers. These portable radios have excellent range, battery life and audio quality in all digital and analog systems, and a full suite of features to enhance safety and productivity. And with integrated Wi-Fi, GPS and Bluetooth 4.0, you can be confident that your radio integrates the latest technology. CO PATIBLE ITH: XPR 5000e POWERFUL AND SOPHISTICATED, FOR THE PROFESSIONAL WHO REFUSES TO COMPROMISE When you need complete connectivity, the XPR 5000e Series delivers. These mobile radios have excellent range and audio quality in all digital and analog systems, and a full suite of features to enhance safety IP SITE C ECT C P CITY PL S C P CITY X C ECT PL S IP SITE CONNECT CAPACITY PLUS CAPACITY MAX CONNECT PLUS PROFESSIONAL ENHANCED TIER ION C ITICAL V ICE. INSTA T DATA. ONE DEVICE. The MOTOTRBO™ Ion smart radio is the first business-ready communi ation device with all-on voice nd broadband data c pabilit es combi es the ependabil ty and ruggedness of a MOTOTRBO two-way r dio with the op n app ecosystem of a Android device. : I I I I MOTOTRBO RADIO SOLUTIONS
16 | 800-503-3433 • WWW.DAYWIRELESS.COM SLR 1000 SERIES REPEATER Using the SLR 1000 repeater, you can easily extend the range of your network through dead zones and across remote locations, so everyone’s within reach. Deploy the SLR 1000 indoors or out—it’s IP65-rated for dust and water protection. The compact size gives you more installation options. And a low power, fanless design uses less space and energy. SLR 5000 SERIES REPEATER A next-generation DMR repeater, the SLR 5000 Series offers high performance, high efficiency and a design for the future. The product has a 50 W continuous-duty output and high sensitivity for optimum coverage, and high reliability and low power consumption for low cost of ownership. With a slim, modular design, the product is easy to install and service. SLR 8000 SERIES REPEATER Built on the slim next-generation repeater platform, this repeater supports up to 100 W continuous-duty operation, with high sensitivity for exceptional coverage. The modular design keeps reliability high while allowing for configurable options. INFRASTRUCTURE Repeaters, controllers and gateways are the backbone of your MOTOTRBO two-way radio system. They ensure your radio network is available at all times and that communications are clear, reliable and secure across your enterprise. CAPACITY MAX SYSTEM SERVER Part of the next-generation Capacity Max trunking solution, the System Server hosts control and management functions. Each server can support up to 100 voice/data talkpaths. Redundant servers can be provisioned to increase system resilience. WAVE GATEWAYS Get WAVE broadband PTT without the startup costs or maintenance that come with servers installed in your facility. Cloud-based WAVE deployments use a simple WAVE Gateway to connect MOTOTRBO Capacity Plus or Capacity Max systems to our WAVE servers in our secure data center. MOTOTRBO RADIO SOLUTIONS
17 | 800-503-3433 • WWW.DAYWIRELESS.COM APPLICATIONS With a wide range of applications and an expert application partners program, MOTOTRBO offers custom solutions that truly meet your business needs. Businessspecific applications like these increase the level of efficiency, safety and productivity throughout your enterprise. MOTOTRBO RADIO SOLUTIONS
18 | 800-503-3433 • WWW.DAYWIRELESS.COM MOTOTRBO RADIO SOLUTIONS COMMAND AND CONTROL These applications work behind the scenes of your MOTOTRBO network to enhance the efficiency and responsiveness of your system. Interfacing to a Work Order Ticketing system, managing alarms and telemetry, and connecting to other messaging systems, they bring significant benefits to your business. PERSONNEL SAFETY Increase the safety and accountability of your staff by deploying these applications. Features such as Man Down and Lone Worker can be linked to indoor and outdoor location services for maximum effectiveness. INTEROPERABILITY Connect your MOTOTRBO radio system to other communication systems. From analog two-way radio systems to SIP telephone networks to cellular providers, you can increase efficiency and increase collaboration. LOCATION Track your vehicles and your staff for improved safety, security and accountability. These applications allow you to make the most of MOTOTRBO’s GPS capabilities, and some even offer indoor location tracking capabilities. SYSTEMMONITORING To get the best from your MOTOTRBO system, you need to know how it’s performing. These applications give you a dashboard view of key metrics and parameters, with detailed logs helping you plan future growth and upgrades. People 1 Group of People Hacker 1 CIO/IT Manager (Male) CIO/IT Manager (Female) Computer Person 1 Computer Person 2 Dispatcher/Call Taker 1 Dispatcher/Call Taker 2 Dispatcher/Call Taker 3 Video Analyst ICC Multiple Agencies People 3 People 2 Command Center Hacker 2 HP ICON LIBRARY7 6/7/13 TEXT MESSAGING AND EMAIL Enhance productivity by connecting your radio network with your text and email system. Allow your staff to use advanced work order ticketing solutions, or simply streamline the flow of information between office and shop floor. VOICE DISPATCH Giving you centralized control of your workforce, these applications offer customizable user interfaces to allow your dispatcher to coordinate your staff efficiently and effectively. They also enhance business connectivity by allowing telephony interconnections and multi-system patching. WORK TICKET MANAGEMENT These applications enhance efficiency and accountability in the workplace using text- based issue management software. They can be integrated with your existing work-order management solution or can be operated as an independent system.
19 | 800-503-3433 • WWW.DAYWIRELESS.COM MOTOTRBO DISPATCH SOLUTIONS Avtec consoles offer tight integration with all MOTOTRBO radio systems. In addition, Scout consoles also integrate with the other standards-based and proprietary radio solutions, broadband Push-to-Talk over Cellular (POC) systems, and telephony technologies you use every day giving you maximum flexibility to select the right technologies. Since the Scout Enterprise suite scales from one console to hundreds, you can count on a solution that grows with you over time, whether that means single-site, multi-site, regional, or mobile configurations. ABOUT AVTEC SCOUT ENTERPRISE: PROVEN, TRUSTED, RELIABLE Avtec’s Scout Enterprise family of dispatch solutions is developed, built and supported in the U.S., and is deployed in some of the largest and most demanding command and control centers throughout North America. Based on a single-code base, Scout Enterprise is engineered to be highly customizable and easily scalable to meet changing operational requirements. Scout is backed by expert support and services through its ScoutCare® licensed, post-warranty software and support service program. SCOUT EX Avtec Scout EX is Avtec’s most robust solution and can monitor up to 250 audio streams and 2,000 channels. If your government agency needs a secure, scalable, and redundant console solution to manage hundreds of resources daily, you can depend on Scout EX. SCOUT E8 Avtec Scout E8 can monitor up to eight audio streams and eight channels at a time, providing maximum value for a minimal investment. And because it is compatible with all Scout Enterprise products, you can easily expand this system as your dispatch communications center grows. SCOUT E4 The Avtec Scout E4 console manages up to four audio streams and eight channels at a time. This costeffective solution is compatible with Scout EX and E8 consoles, so you can add additional software licenses when you need them. SCOUT E1 Avtec Scout E1 is a purpose-built hardware device that delivers a compact, reliable, and affordable dispatching solution for up to four radios. The E1 works as a stand-alone piece or can be combined with multiple E1 devices to create a larger system. Since Scout E1 is compatible with all Scout Enterprise products, it can be easily upgraded. No matter if your communication needs are simple, highly complex or somewhere in between, there’s a Scout Enterprise solution for you. See which best fulfills your need for secure, converged audio and radio dispatch communications. MOTOTRBO RADIO SOLUTIONS
20 | 800-503-3433 • WWW.DAYWIRELESS.COM DISCOVER THE ULTIMATE IN SEAMLESS OPERATIONS WITH A TOTAL MOTOTRBO SOLUTION MOTOTRBO A COMPLETE END-TO-END SOLUTION RADIOS From simple voiceonly models to feature-rich voice and data radios SYSTEMS MOTOTRBO offers a wide range of systems that can evolve with your business APPLICATIONS Leverage data applications from our application developer program to enhance your communications SERVICES We’ve got you covered, from preinstallation to post-implementation, with expert support ACCESSORIES A complete portfolio of accessories optimizes the performance of your MOTOTRBO radio CONSOLES & MANAGEMENT Centralize management of your radio network and workforce for effective, efficient communications INFRASTRUCTURE Repeaters, controllers and gateways are the backbone of your MOTOTRBO two-way radio system MOTOTRBO RADIO SOLUTIONS
21 | 800-503-3433 • WWW.DAYWIRELESS.COM INSTANTANEOUS PTT COMMUNICATION Nothing is faster than push-to-talk (PTT) when you need a quick answer or immediate emergency response. It provides real time communication for individuals or groups across your entire team from the control room to the front-line, resulting in loyal customers, satisfied employees and increased business. HEAR AND BE HEARD CLEARLY IN NOISY ENVIRONMENTS Superb audio quality means MOTOTRBO delivers crystal-clear communications. The Intelligent Audio feature automatically adjusts radio volume up and down in response to the level of noise in the workplace. And with MOTOTRBO’s background noise suppression, you can be confident communication is loud and clear. REACH YOUR WORKFORCE WHEREVER THEY GO Hear calls clearly over a greater range. MOTOTRBO features advanced digital signal processing to deliver voice integrity and clarity to the limits of coverage. And thanks to DMR TDMA technology, MOTOTRBO delivers twice the call capacity of analog radios so more workers can use voice and data, without worrying about privacy or interference. KEEP COMMUNICATING FOR LONGER Because MOTOTRBO radios use much less power in digital mode than analog, batteries last significantly longer on a single charge. CHOOSE THE RIGHT SOLUTIONS FOR THE RIGHT USERS Whether you want ultra-light portables or extratough mobiles, integrated Bluetooth® and WiFi® or industry-leading data applications, MOTOTRBO has the right devices and systems to fit your workforce now, and allows you to evolve as your enterprise grows. MOVE FROM ANALOG TO DIGITAL WITH EASE Migrate at your own pace, one talk group or department at a time. MOTOTRBO radios operate in both analog and digital mode, so you can use them on your existing analog system and move to digital when you’re ready – all while running operations smoothly. GET ADVANCED CAPABILITIES AND BUSINESS-CRITICAL FEATURES MOTOTRBO has innovative features such as Transmit Interrupt, which lets you prioritize communication the moment it’s needed. Man Down and Lone Worker applications call for help when personnel can’t. GPS location tracking monitors vehicles, assets and the user in real time. LEVERAGE EXPERT APPLICATIONS THAT GET THE JOB DONE EFFICIENTLY MOTOTRBO fits the way businesses run today, with an expert Application Developer Program that helps you customize your communication solution to your environment and workforce. Solutions range from text messaging, centralised dispatch and GPS tracking to personnel monitoring and work order ticket management. Applications like these make it easier to accomplish multiple tasks on a single purpose-built device. KEEP CONNECTED WHEN CONDITIONS ARE TOUGHEST MOTOTRBO is made to last. Our rugged, waterproof and intrinsically safe radios endure a rigorous Accelerated Life Testing (ALT) purpose-built device which simulates up to 5 years of field use. We design and engineer MOTOTRBO products to survive the harsh conditions of everyday business. REACH EVERYONE, ANYWHERE When you’re running a professional operation, you need more than just radio-to-radio communications. MOTOTRBO has coverage options to suit your needs - whether you’re operating in a single building, a large campus, or even multiple locations around the world. Connecting thousands of radio and smartphone users in a single location, your capacity options are virtually unlimited. Having MOTOTRBO at the heart of your organization will help you achieve new levels of productivity, safety and efficiency. The extensive portfolio means you can custom-build your complete solution including radios, infrastructure, systems, accessories, applications and services designed around what you need today and in the future. MOTOTRBO RADIO SOLUTIONS PAGE 8 RADIO ACCESSORIES From discreet Bluetooth earpieces to efficient battery solutions, our complete portfolio of accessories optimizes the performance of your MOTOTRBO radio. They are designed to h lp you perform your best, wherever you work, nd unleash the power of the industry’s most advanced digital radio platform. BLUETOOTH® WIRELESS FOR PORTABLE ANDMOBILE RADIOS Unleash the power of your MOTOTRBO radio without wires getting in the way. Our extensive suite of Bluetooth acc ssories free you to take the radio off your belt, leave your truck or step away from your desk (up to 30 feet way) and stay connected. Choose from a vari ty of arpieces, heavy duty wireless heads ts and push-to-talk solutions that let you move without constraints around the workplace. EARPIECES Transmit and receive discreetly with a variety of earpieces that feature a streamlined design and rugged cables that withstand tough conditions. With in-line push-to-talk and microphones, they’re easy to use on the go. Our flexible array of urveillance kits includes two-wire kits (one wire for receivin , one wire f r transmitting) and more discreet three-wire kits (separ te wires for transmitting, r ceiving and p h-to talk). HEADSETS Protect hearing and facilitate communications in noisy environme ts. Select from a wide range of comfortable, durable, lightweight to heavy duty headsets with noise-canceling boom microphones and in-line push-to-talk. CATALOG MOTOTRBO AT A GLANCE
22 | 800-503-3433 • WWW.DAYWIRELESS.COM MOTOTRBO RADIO SOLUTIONS PAGE 9 BATTERIES AND CHARGERS MOTOTRBO batteries are developed, tested and certified for optimal performance with your MOTOTRBO radios and they outperform other brands of batteries. IMPRES batteries can be charged 150 additional times versus a standard battery – a 43% increase in charge cycles. IMPRES Over the Air Battery Management automatically collects battery information over the air while radios are in use, making battery management easier than ever. REMOTE SPEAKER MICROPHONES (RSM) Communicate clearly in loud workplaces. MOTOTRBO RSMs have exclusive audio features like windporting for windy outdoor environments and noise-canceling to reduce background noise. Exclusive IMPRES technology ensures your voice is heard clearer and more loudly over a wide range of conditions and the INC RSM suppresses extreme noise from high decibel equipment and heavy machinery so you can be heard above all. MOBILE RADIOMICROPHONES Choose microphones designed to keep workers safely connected on the move. Keypad microphones let you easily navigate menus on your radios, dial phone numbers and send text messages. The Long Range Wireless Remote Speaker Microphone (RSM) allows you to stay in touch even on remote job sites when you depend on your mobile radio but have to work outside your vehicle. It pairs instantly to the mobile microphone with Bluetooth gateway. CARRY SOLUTIONS Carrying cases are available in sizes designed to fit your radio and battery and permit audio to be heard clearly. Our carry accessories keep your hands free, so you can concentrate on the task at hand. Choose from a wide range of nylon cases, leather cases, straps, holsters and clips, all designed to keep your radio protected, yet still easy to access. INSTALLATION ANDMOUNTING KITS Mounting kits give you the flexibility to mount the radio under or in your dashboard, between seats or on the floor. Remote mount kits allow you to mount the radio in the truck when dash space is limited. CATALOG MOTOTRBO AT A GLANCE
23 | 800-503-3433 • WWW.DAYWIRELESS.COM WAVE PTX (PUSH-TO-TALK SERVICE)
24 | 800-503-3433 • WWW.DAYWIRELESS.COM WAVE PTX™ (PUSH-TO-TALK SERVICE) Connect your team with broadband push-to-talk across different devices, networks or geographic boundaries with a subscription-based communication service. Broadband PTT operates on LTE, so healthcare organizations get the speed and simplicity of professional radio PTT communications with the ability to share details via text, photo, video, or file attachment. WAVE PTX extends a radio system’s reach to those who don’t carry radios. This solution runs on existing devices such as smartphones and tablets so all staff can reach each other, across campuses and facilities and in real-time during emergencies. VIDEO WAVE PTX (PUSH-TO-TALK SERVICE)
25 | 800-503-3433 • WWW.DAYWIRELESS.COM THE WAVE SEAMLESS PORTFOLIO Communication Options That Work the Way You Do. Select the communication tool that best fits your role and responsibility. WAVE TLK 100 PORTABLE TWO-WAY RADIO The WAVE TLK 100 portable two-way radio is a powerful and slim PTT-enabled two-way radio that allows your employees to stay connected anywhere in the nation. They just press a single button for direct PTT voice access to colleagues, delivered with crisp, clear audio. Purpose-built for rugged use across a range of often chaotic, loud, or dispersed worksites. There is no distracting, breakable screen. No texting, applications, or email to get in the way. With singlebutton operations and battery life sure to outlive any smartphone, employees can get started immediately with a greatly reduced learning curve. • Nationwide Push-to-Talk – Increase productivity with a nationwide push-to-talk network that powers the quickest push-to-talk setup and call times. • Easy to Use and Manage – Communicate instantly and manage your business effortlessly by handling talkgroups and subscriptions in real time. • Built for the Job – Get the job done with a rugged two-way radio that is built for business with location tracking and Wi-Fi calling. WAVE TLK 150 MOBILE TWO-WAY RADIO The TLK 150 mobile two-way radio powered by WAVE is an affordable, purpose-built, broadband device that allows countrywide team communications, and helps users comply with the Federal Motor Carrier Safety Administration (FMCSA) regulations for driver distractions. More reliable, more efficient, and easier to use than a smartphone, the TLK 150 gives you everything you appreciate about two-way radio – and more. Purpose-built for organizations and fleets where in-vehicle communication is paramount, the radios combine power with simplicity – providing instant information without distraction. • Operate Safely in Vehicles – Use the one button PTT microphone or take advantage a variety of hands-free accessories to operate safely on the road and stay within FMCSA regulations for driver distraction. • High Quality Audio – Hear conversations clearly while on the road, no matter if communication is held through the compact microphone, visor microphone, or external speaker. • Powerful, Compact Design – Operate seamlessly with a small, compact device that can be mounted in multiple places in a vehicle. VIDEO WAVE PTX (PUSH-TO-TALK SERVICE)
26 | 800-503-3433 • WWW.DAYWIRELESS.COM WAVE PTX (PUSH-TO-TALK SERVICE) WAVE PTX™ MOBILE APP BROADBAND PTT APPLICATION SINGLE APP. MULTIPLE MEDIA. ONE APPLICATION AND TWO MODES PTT Radio for the experience of conventional radio, and Standard for device-based management of contacts and talkgroups. MULTIMEDIA MESSAGING Increase the speed and clarity of information via text, photo, video or file attachment. LOCATION AND MAPPING Track your team on a map, share your location, find an address or set a meeting place.
27 | 800-503-3433 • WWW.DAYWIRELESS.COM WAVE PTX (PUSH-TO-TALK SERVICE) FLEXIBLE CHOICE OF DEVICES AND ACCESSORIES Get the right tool for the job – choose the smartphone or tablet you prefer and the accessories that best t your needs and budget. Smartphones and tablets Android and iOS Accessories Add accessories like headsets, earpieces and remote speaker microphones to help users get the most from their device PTT Communications – Fast, secure and reliable PTT voice communication at the touch of a button. Collaborate with ianndividual, prede ned group or ad hoc groups created on the y. IntegratedMessaging – Push text, video, audio, photos and les to individuals or groups. See threaded hitsory for communication details. Store and forward is supported for o ine users. Mapping and Location – Find an address, coordinate a meetnig place or share your location withothers. StreamingVideo – Optional feature that allows users to share real-time video at the push of a buttonin, creasing communication clarity and improving situational awareness. SafeGuard Package – add this optional set of 3GPP MCPTT-based features to improve safety, situational awareness, and operational e ciency for all WAVE PTX users. Real-Time Presence – Set your status and see who is available with real-time presence information – Available,Do Not Disturb or O ine. KEY FEATURES PTT Co munications – Fast, secure and reliable PTT voice communication at the touch of a button. Collaborate with an individual, predefined group or ad hoc groups created on the fly. Integrated Messaging – Push text, video, audio, photos and files to individuals or groups. See threaded history f r communication details. Store and forward is supported for offline users. Ma ping and Location – Find an a dress, coordinate a meeting place or share your location with others. Streaming Video – Optional feature th t allow u ers to share real-time video a the push of a button, increasing communication clarity and improving situation l aw reness. SafeGuard Package – i ti l f 3GP MCPTT-bas features to improve safety, situational awareness, and operational efficiency for all WAVE PTX users. Real-Time Presence – Set your status and see who is available with realtime pr sence information – Avail ble, Do Not Disturb or Offline. ES: OPTIONAL ADD ONS Streaming Video – Optional feature that allows users to share real-time video at the push of a button, increasing communication clarity and improving situational awareness. SafeGuard Package – add this optional set of 3GPP MCPTT-based features to improve safety, situational awareness, and operational efficiency for all WAVE PTX users.
28 | 800-503-3433 • WWW.DAYWIRELESS.COM WAVE PTX STREAMING VIDEO VIEW EVENTS AND ACTIVITIES AS THEY HAPPEN WAVE PTX STREAMING VIDEO SEE A REAL-TIME VIEW OF EVENTS AS THEY HAPPEN How many times has someone said, “if they could only see what I see” when trying to convey verbally to another person what’s going on around them? That’s because using words to paint a mental image of what’s happening at that moment can be a frustrating and time-consuming experience. Whether someone is a shopping mall security guard watching a food fight grow, an HVAC technician experiencing problems with a new install procedure or an EMT dealing with a critical patient, the ability to stream video in real time is the key to increasing the speed and clarity of their communications. Compliant with the 3rd Generation Partnership Project (3GPP) Mission Critical Video (MCVideo) standard, WAVE PTX Streaming Video makes it possible for users to push live video to individuals, groups, or dispatchers. The result is increased situational awareness for dispatchers, supervisors, and other recipients because they have a realtime view of events and activities as they happen. To stream video to a group, the originator selects the talkgroup for the video call. To start the group call, the originator again taps the video icon located to the left of the PTT button. Streaming starts when the first member of the talkgroup accepts the incoming video call, and the stream is available to any member of the group that is configured to receive group video. Please note that originators can make a streaming video call to a talkgroup even if they are not configured to receive group video calls. For both individual and group streaming, the PTT call audio and video audio can be mixed, or the PTT call audio can have priority. In addition, the originator has the option of choosing which camera, front, or rear, to broadcast. The originator can also tap the video call screen to minimize the video and tap the microphone icon to mute or unmute the audio sent with the live video stream. COMBINE VIDEO AND AUDIO IN A SINGLE, INSTANTANEOUS COMMUNICATIONS SESSION The optional Streaming Video feature allows WAVE PTX broadband PTT mobile users to push live H.264 video, with audio, from their device’s integrated camera(s). The streaming video recipients can be any assigned contacts or groups that are capable of receiving video calls. Each video session can have just a single originator, and each participant can have only one active video call at a time. To stream video to an individual, the originator taps the Contacts button to display the list of contacts and selects the one with whom to start a video call. To start the oneto-one video call, the originator taps the video icon located to the left of the on-screen PTT button. When the contact accepts the incoming video call, streaming begins. To end the streaming video call, either the originator or recipient can tap the end call button. THEY SEE WHAT I SEE By integrating streaming video in a single push-to-talk application, originators have a tool that brings the robustness of face-to -face communications to remote communication. Because recipients see what they are seeing, originators can combine video and voice in a single, instantaneous communications session to increase the speed and efficiency of their communication.
29 | 800-503-3433 • WWW.DAYWIRELESS.COM WAVE PTX EMERGENCY CALLING AND ALERTING EMERGENCY CALLING AND ALERTING PRIORITIZE PTT CALLING TO ENHANCE WORKER SAFETY Whether you are an undercover officer in need of assistance during an arrest, a utility worker injured at a remote job site, or an EMT dealing with a hallucinating patient, you need priority communication with those who can help at the touch of a button. Compliant with the 3rd Generation Partnership Project (3GPP) Mission Critical Push-to-Talk (MCPTT) standard, Emergency Calling and Alerting from Motorola Solutions makes it possible for those in immediate danger to quickly communicate with the individuals or groups who can provide assistance. With the push of a button, users can declare an emergency to ensure that all broadband PTT communication is immediately routed, with the highest priority, to the designated individual or group. The result is enhanced worker safety, particularly for those working alone. INITIATE AN EMERGENCY CALL Users press a hard or soft dedicated button to initiate an emergency call to an individual or group. For broadband PTT users whose safety is threatened, declaring an emergency is as simple as pressing and holding the emergency button in the application, or dedicated button on the device or accessory, to place the application in an emergency state. The application will display “emergency declared”, and all broadband PTT calls from the device will be treated as emergency calls with the highest priority. After entering the emergency state, the broadband PTT user can manually push the same button to place an emergency call. Alternatively, the administrator can set up the user for automatic emergency calling in which the floor is automatically held by the broadband PTT application for 10 seconds. If during that time there is no user interaction, the floor is released. For both manual and automatic emergency calling, the destination will be the same as the recipient(s) of the emergency alert. Authorized users, such as dispatchers and supervisors, can also originate emergency calls on behalf of specific users, participating in the call in case of a life-threatening situation. Broadband PTT users can cancel their emergency state at any time, or an authorized user (supervisor or dispatcher) can cancel their emergency state for them. In addition to supporting emergency calls initiated by broadband PTT users, Emergency Calling and Alerting makes it possible for emergency alerts originated by P25 land mobile radio (LMR) users to be shared with broadband PTT users. P25 users who are part of an ISSI interoperability talkgroup can have their emergency calls routed to broadband PTT users with the same priority and preemption as those originated on the broadband PTT system. Providing interoperability for P25-originated emergency calls ensures that any worker whose safety is threatened is able to reach the right resource for assistance, regardless of the network they are using. ORIGINATOR
