Motorola SLR 5700 Repeater (MOTOTRBO SLR5700)

SLR 5700 Repeater

The Motorola SLR 5700 is the next generation of MOTOTRBO repeaters — combining rock-solid reliability with a sleek 1U rack-mount form factor and industry-leading low power consumption. Whether you're expanding coverage across a warehouse floor, a campus, or a wide-area network, the SLR5700 delivers 50 watts of continuous transmit power with crystal-clear digital voice quality.

Designed for businesses that can't afford downtime, the Motorola SLR 5700 repeater has been validated through Motorola's Accelerated Life Testing (ALT) program. Its next-generation receiver delivers high sensitivity and improved noise rejection — so your team stays connected even in the most challenging RF environments.

The SLR 5700 supports the full MOTOTRBO feature set and is compatible with every MOTOTRBO system architecture: single-site conventional, IP Site Connect, Capacity Plus, Linked Capacity Plus, Capacity Max, and Connect Plus. Built with 10× more processing power, 15× more memory, and 125× more data storage than first-generation repeaters, the SLR5700 is engineered to grow with your organization.

SLR 5700 Key Features

• 50W continuous transmit power — full-duty-cycle operation 24/7
• VHF (136–174 MHz) and UHF (400–512 MHz) frequency options
• 64-channel capacity with digital and analog support
• Mixed analog/digital mode for seamless migration from legacy systems
• Integrated 3A battery charger — true one-box installation
• 7 LED front panel array and front-panel USB port for easy configuration
• Dual RJ-45 Ethernet ports for IP network integration
• RDAC support — remote diagnostics, alarms, and controls
• Compatible with all MOTOTRBO architectures: Conventional, IP Site Connect, Capacity Plus, Linked Capacity Plus, Capacity Max, Connect Plus
• 5-year Motorola warranty included

Why Choose the Motorola SLR 5700?

The SLR 5700 (also known internationally as the SLR 5500) is one of the most widely deployed MOTOTRBO repeaters in North America. Its compact 1U rack profile, internal power supply, and optional duplexer support make it the go-to choice for system designers who need maximum flexibility with minimal rack space.

As an authorized Motorola Solutions dealer and Service Elite Specialist, Day Wireless provides expert SLR 5700 configuration, installation, and support across Oregon, Washington, California, Idaho, Utah, and Wyoming. Whether you're building a new MOTOTRBO system from scratch or adding coverage to an existing network, our engineers will size and commission your SLR5700 installation correctly the first time.

Popular SLR 5700 Use Cases

• Expanding two-way radio coverage in large facilities (warehouses, hospitals, campuses)
• Building out Capacity Plus single-site trunked systems
• IP Site Connect links between geographically separated sites
• Analog-to-digital migration with mixed-mode operation

Industries Served

• Education
• Construction
• Healthcare
• Hospitality
• Manufacturing
• Property Management
• Warehouse & Logistics

Frequently Asked Questions — Motorola SLR 5700

What is the difference between the SLR 5700 and SLR 5500?

The SLR 5700 is the North American model (USA and Canada), while the SLR 5500 is sold in EMEA, Australia, and New Zealand. They are functionally nearly identical but carry different regional type approvals.

What is the difference between the SLR 5700 and SLR 8000?

The SLR 5700 is a 50W, 1U repeater available in VHF and UHF. The SLR 8000 is a higher-power 100W, 2U unit that also supports 800/900 MHz bands, making it the preferred choice for large-area or high-power deployments.

Does the SLR 5700 support Capacity Max?

Yes. The SLR5700 supports the full MOTOTRBO system architecture lineup including Capacity Max, Capacity Plus, Linked Capacity Plus, Connect Plus, IP Site Connect, and conventional analog and digital modes.

Does the SLR 5700 require an FCC license?

Yes. Operating a two-way radio repeater requires an FCC license. Day Wireless processes hundreds of FCC license applications annually and can assist you with licensing when you purchase your SLR 5700 system.

Can I get a quote for the Motorola SLR 5700?

Motorola does not allow online pricing to be displayed on the SLR 5700. Contact Day Wireless for current pricing and availability across our 30 locations.
